1000W 1500W 2000W 3000W Fiber Laser Cleaner Rust Removal With PLC Control System

1000W 1500W 2000W 3000W Fiber Laser Cleaner Rust Removal With PLC Control System

1000W 1500W 2000W 3000W Fiber Laser Cleaner Rust Removal With PLC Control System
1000W 1500W 2000W 3000W Fiber Laser Cleaner Rust Removal With PLC Control System
1000W 1500W 2000W 3000W Fiber Laser Cleaner Rust Removal With PLC Control System
Product Details:
Place of Origin: P.R.CHINA
Brand Name: OTA
Certification: CE, ISO
Model Number: OTQX-1000
Payment & Shipping Terms:
Minimum Order Quantity: 1SET
Price: USD2350-USD5980
Packaging Details: WOODEN CASE
Delivery Time: 10-15DAYS
Payment Terms: L/C, D/P, T/T, Western Union
Supply Ability: 2000SETS/MONTH
Contact Now
Detailed Product Description
Product Name: Fiber Laser Cleaner Rust Removal Cleaning Depth: 0-1mm
Cleaning Efficiency: ≥99.9% Control System: PLC
Cooling System: Air Cooling Laser Pulse Frequency: 1-20KHz
Laser Wavelength: 10.6um Power Supply: 220V/50Hz
Scanning Angle: 0-360° Scanning Speed: 1-1000mm/s
Spot Size: 0.1-3mm
Highlight:

1000W Fiber Laser Cleaner Rust Removal

,

3000W Fiber Laser Cleaner Rust Removal

,

3000 watt laser cleaner

1000w 1500w 2000w 3000W Rust Paint Removing Machine Fiber Laser Cleaner

Product descriptions:

Laser cleaning machine is an efficient and environmentally friendly cleaning equipment. It uses high-energy laser beams to irradiate the surface of objects to quickly evaporate or peel off stains and oil stains on the surface, thereby achieving the purpose of cleaning. Compared with traditional cleaning methods, laser cleaning machines have many advantages. First of all, it can quickly clean stains and oil on the surface of various materials, and the cleaning effect is very good. It can clean the surface thoroughly without leaving any traces.



Secondly, the laser beam energy used by the laser cleaning machine is highly concentrated and will not cause damage or destruction to the surface of the object. Therefore, it is particularly suitable for cleaning some high-precision and high-value items. In addition, laser cleaning machines also have the advantages of high efficiency, environmental protection, and remote operation, and are widely used in industry, medical, scientific research and other fields.



In short, the laser cleaning machine is a very advanced cleaning equipment, and its emergence has brought great convenience and benefits to many industries.

1000W 1500W 2000W 3000W Fiber Laser Cleaner Rust Removal With PLC Control System 0
1000W 1500W 2000W 3000W Fiber Laser Cleaner Rust Removal With PLC Control System 1
1000W 1500W 2000W 3000W Fiber Laser Cleaner Rust Removal With PLC Control System 2
1000W 1500W 2000W 3000W Fiber Laser Cleaner Rust Removal With PLC Control System 3
1000W 1500W 2000W 3000W Fiber Laser Cleaner Rust Removal With PLC Control System 4

1000W 1500W 2000W 3000W Fiber Laser Cleaner Rust Removal With PLC Control System 5

Product Specification
Mode OTQX-1000 OTQX-1500 OTQX-2000 OTQX-3000
Laser source power 1000w 1500w 2000w 3000w
Laser wavelength 1080±10mm
Laser type Continuous/Modulation
Maximum Modulation Frequency 20khz
Cable length 10m(15m can be customized)20m(Standard for BLC3000
Scan Width 10-160mm
Power configuration AC 220V±10% AC 380V±7%
  6KW 8KW 10KW 13KW
Cooling method Water cooling (Medium:Deionized water,distilled water or purified water )
Machine Dimension 845*460*605mm 905*480*630mm 1240*584*1148m
m
Packing Dimension 1120*565*1050mm 1430*720*1220m
m
Net weight 106kg 113kg 137kg 235kg
Gross Weight 138kg 145kg 169kg 280kg
Water tank
Capacity
16L(14-15L of water to be added


Features

1) Powerful, short pulses, fast moving laser pulses act on the surface of the target, producing tiny plasma ruptures, shock waves,thermal stress, etc., causing surface materials to sublimate and evaporate.
2) The focused laser beam is capable of accurately evaporating surface objects or dirt.
3) Fiber Laser cleaning is suitable for metal surfaces. The treated and optimized laser beam does not alter metal properties or damage those laser treated surfaces. The precisely tuned laser beam acts only on the coating, residual residue or oxide, and does not harm the underlying parent metal surface.
4) By adjusting other parameters, the laser beam is able to achieve the desired cleaning effect accurately and easily.

Factory & Stocks
1000W 1500W 2000W 3000W Fiber Laser Cleaner Rust Removal With PLC Control System 6
Packing & shipping
1000W 1500W 2000W 3000W Fiber Laser Cleaner Rust Removal With PLC Control System 7
Certificate
1000W 1500W 2000W 3000W Fiber Laser Cleaner Rust Removal With PLC Control System 8
FAQ:

1. What is the speed of the laser cleaning machine?
Different laser types determine the cleaning speed of the cleaning machine,and the cleaning speed is within the range of 0.5m²/h-15m²/h
2.Is it possible to clean the mold?
Yes,You can give us your mailbox, and we will send the video of the laser cleaning machine cleaning the mold to your mailbox
3.The effect of paint and rust removal Very good, you can refer to our video below
4.Is there any damage to the cleaning material?
Depends on what type you need, the pulse type has a finer cleaning effect, and the continuous type has a faster cleaning speed,Relative damage of material, pulse type is less than continuous type.
5.Language interface
Support Chinese and English, and language settings can also be set according to customer needs
6.classification of cleaning
objects oxide layer/rusty scale/Paint, coating/Dirt, carbon layer/Others
